Six Bars Heavy Duty Metal Oval Rail Cattle Yard Panel for Australia
Specification
1>round style
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | more than 15 microns |
| Height x Length | 1800mm x 2100mm |
| vertical pipe | 32mm O.D x1.6mm thickness 42mm O.D x 1.6 mm thickness |
| horizontal rails | 32mm O.D x1.6mm thickness 42mm O.D X 1.6mm thickness (6 round rails) |
| Welding | Fully welded post brackets |
| welds | bull bars are fully welded, each weld is protected with epoxy paint |
2>square tube style
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe | 50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness |
| horizontal rails | 50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness (6 square rails) |
| Welding | Fully welded post brackets |
| welds | bull bars are fully welded, each weld is protected with epoxy paint |
3> oval tube style
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe | 50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness |
| horizontal rails | 30x60mm oval rail x 1.6mm thickness 40x80mm oval rail x 1.6mm thickness 40x120mm oval rail x 1.6mm thickness (6 oval rails) |
| Welding | Fully welded post brackets |
| welds | bull bars are fully welded, each weld is protected with epoxy paint |
4>cattle panel gate
| Height x Length: | 2200mm x 2000mm |
| Frame: | Horizontal & Vertical pipe: 50 mm x 50 mm RHS x 1.8 mm thick with
fully welded caps |
| Cattle Gate Horizontal rail: | 40 mm x 80 mm x 1.6mm thick x 6 oval rails |
| Finishing: | hot dipped galvanized ,zinc coating:more than 15 microns. Fully welded oval pipes, post &brackets ,heavy duty hinges |
We are professional manufacturer of steel fence,temporary
fence,cattle panels and exported to Australia,America,Canada etc
for many times and get pretty good feedback from our customers.
And each of our products strives for perfection, each product
condenses our sweat, and also contains many customers'
Suggestions.We believe that in the future work, friends from all
circles will give us more support and let us cooperate more
happily.
A TOP range BULL panel, a superior heavy duty panel that is built
from 50mm x 50mm uprights and 1.6mm thick, with 5 ovals 120mm x
30mm and 1.8mm thick, comes with pins and brackets to lock the
panels together, metal capped to keep the rain out, and bottom
plated to make sure you can secure them to the ground.
This product is sturdy and reliable and there is no fear that the
structure will collapse. It is made from the highest quality of
galvanized steel and chain link mesh.
Cattle yard panel is usually called cattle panel, horse
panel,livestock panel,corral panel etc.
It is made with welded hot dip galvanized pipes for the use of
fencing livestocks, such as cattle,cow,bull,calves,Dairy
sheep,goat,dog.
Jiangrui supply quality cattle panels, horse panels, sheep panels
and custom made panels suitable for all livestock.
All products are manufactured using high quality pre-galvanised RHS
& pipe.
A versatile cattle panel with rounded edges that can be used as a
cattle panel, horse panel or sheep panel.
Extra C and L lugs can be supplied to integrate panels into an
existing yard.
1 pallet packing to save cost for customer
2 rich experienced sales team to help to win market share for you
3 experienced logistic supporting to keep to delivery the holland
fence sately, fastly and with lower cost.
4 self control from the maerial to pvc coated welded fence progress
to galvanizing, and paiting to keep satisfied quality.
When can you get the reply?
Within 2 hours after we get your inquiry.
What you’re getting before any work starts?
We will provide a drawing with your quotation, so you can see what
your new fencing will look like.
All costs will be clear?
Our quotations are straightforward and easy to understand.
You will be pleased to know we have all necessary accreditation.
Please click on the professional certification to see our
certificates
